Copper Falls

  • Beds: 2
  • Baths: 1
  • Sq Ft: 1476
CopperFalls b

Description

Priced as Wisconsin Build
Display Home Includes the following features and optional upgrades:

FOUNDATION
8” x 8 Ft High Poured Basement Walls over 8" x 16" Footing
1/2 " Rebar per Code
16 x 32 White Vinyl Windows 2- Std.
Foundation will have One Coat of Tar on Exterior Walls
4 " Drain Tile System Installed Both Inside and Outside of Footings Drain Tile and Ran to Sealed Crock
Washed Stone Installed Over Drain Tile System
Filter Cloth Installed Over Exterior Drain Tile System
Basement Floor approx. 4 in Thickness
¾ Stone Put in Before the Concrete Floor is poured
6 Mil Poly Vapor Barrier will be Laid down before Concrete Floor is poured
Digging and Backfilling Foundation to Rough Grade
BASEMENT MATERIAL
Jack Post 3” or 4” FHA Approved
Sill Plate 2x6 Treated Wood
Foam Insulated Sill Seal
FLOOR SYSTEMS
Floor Joist: 2 X 10
Ring Joist: 2 X 10
Bridging: 1” x 3” Wood or Equivalent
Deck: ¾” tongue and groove OSB (oriented strand board)
Glued and Nailed
EXTERIOR WALL
Studs: 2 x 6 x 92 - 5/8” SPF stud grade 16” O.C.
Plates: 2 x 6 SPF # 2 Lumber or Better
Double Top Plate and Single Bottom Plate
Exterior Wall Sheathing: 7/16” OSB (oriented strand board)
Tyvek House Wrap Vapor Barrier over OSB with taped seams
Drapery Rod Backer: 2 x wood blocking at top of each side of rough opening
Exterior Siding: Double 4” - Solid Color - Textured Vinyl Siding with Vinyl Corners Optional: Deluxe Colors, Premium Colors, Wood Grain Siding, Cement Board-Log-Cedar etc.
ROOF & CEILING CONSTRUCTION
Ceiling: 8 Ft Flat Ceilings and Vaulted Ceilings
Attic Ventilation: Continuous Soffit Vent
Vinyl Ridge Vent (shingle over top)
Roof Trusses: Modified Energy Truss 7 3/8” Heel
Roof Pitch: 10/12
Overhang: 18 “Eaves w/ 12 “Rakes (gable ends)
Gable: Sheathed 7/16" OSB
Roof Sheathing: 1/2" OSB with H- Clips
Shingle Underlayment: 15 # Felt
Ice and Water Shield: Applied to Eaves of Home
Shingle: CertainTeed 30 Year
WINDOWS
Window: JELD-WEN Vinyl Single Hung Insulated w/Argon Gas, Low E Thermo pane.
EXTERIOR DOORS
Front Door: 36" Insulated 6 Panel Steel with Extruded Aluminum Jamb and Brick
INTERIOR WALLS
Non-Load Bearing: 2x4 SPF Stud Grade - 16” O.C.
Load Bearing: 2x4 SPF or 2x6 SPF Stud Grade, - 16” O.C.
Basement Stairs: Closed Riser Particle Board Treads with unfinished Pine Handrail Optional: Finished Stairs - Open Staircase with 1/2 Wall
OPTIONAL UPGRADES
Upgrade to wood extension jambs and Oak casing
Upgrade trapezoid windows from single to enlarged 3 wide windows and Upgrade patio doors from 6' wide Std. to 7'6" 3 wide
Upgrade entry door to fiberglass prefinished with window
Upgrade to optional Prow (extends center out 4')
Upgrade width from 24' wide plan to a 26' wide plan
Upgrade siding from Std. Vinyl to LP SmartSide trim & siding Limited (Product Warranty 5/50 year) and with Diamond Kote Premium color finish (Finish Limited Warranty : 30 years on finish including labor for the first 7 years)

Listing Details

Type:Site Built
Style:Chalet
Model Type:Custom built
Floors:1 + loft
Square Feet:1476
Bedrooms:2
Bathrooms:1
Tagged Features
  • Type/Style:

    Site Built
    Chalet, Custom built

  • Beds: 2
  • Baths: 1
  • Sq Ft: 1476
